ECO Newton TS-50

Closing force 1 – 5,  tested acc. to EN 1154  (for door widths up to 1.250 mm) continuously adjustable. Latching speed and closing speed continuously adjustable. Back-check constant. Same version DIN left and DIN right. Mounting height only 41 mm. Weight: 1.280 g. Max. door opening angle: 180°

Hinge side: Standard mounting on door leaf. Hinge-opposite side: Head mounting on door frame.

New packaging:

TS-50 Standard: (Standard mounting set)  incl. door closer body, standard arm, paper template and fixing material.
TS-50 DIN: (Mounting acc. DIN holes) Set with door closer body, standard arm, incl. mounting plate, ­mounting instructions, paper template and ­fixing material.

Features
  • ECO unity: The ECO Newton closer portfolio covers all door dimensions with only two basic closer units.
  • ECO clic: The stainless steel cover encloses the aluminium body with the power of spring steel and conceals all of the adjusting elements, thus securing the closer against unauthorized access.
  • ECO mount: Optional mounting plate according to EN 1154, supplementary sheet 1
  • ECO valve: Simple, high-precision and permanently secure adjustment of all parameters of the closing process with one conventional Allen key.
  • ECO cover2: Optional stainless steel cover for the ECO Newton door closers.
  • ECO green: The intelligent construction and carefully planned use of materials help considerably to save resources.
Download Catalogues



Product Information TS-50







Mounting Instructions TS-50







Certificates EN 1154 TS-50
